1. Remove the top cover of the camera to access the SD card slot.
2. Insert the SD card into the slot.
3. Connect the power cord to the camera's power hole on the top.
4. Place the camera back in its original position.
1. Connect the camera's power cord to the roof.
2. The roof is vertically on the front of the body shell.
3. Align the roof's points with the slots on each side of the body.
4. Press down slightly until you hear a snap, securing the roof in place.
5. Rotate the roof by 90 degrees to complete the installation.
1. Find the two round holes on the front of the bird feeder.
2. Place the bird stand support in these two round holes.
3. Secure the bird feeder body with two screws from the bottom.
1. Attach the drill sticker to the desired tree location.
2. Use the four drill holes on the sticker as screw guides.
3. Drill four holes in the tree as marked.
4. Insert screw sleeves and twist screws into the holes.
5. Mount the L bracket on the tree at an even level for convenient access.
1. Insert the large notch into the white component.
2. Align the screw holes on the bird feeder with the holes on the white component.
3. Secure the bird feeder and white component using the provided screws and nuts.
4. Ensure proper alignment using the blue dot on the bottom of the bird feeder.
1. Locate the power switch on the top of the camera.
2. Open the rubber cover to access the switch.
3. Twist the power switch to turn on the camera.
1. Open the instruction manual and locate the QR code.
2. Use your phone to scan the QR code.
3. This will redirect you to the app store to download the "Bird Lover" app.
1. Open the "Bird Lover" app on your phone.
2. A dialog box will appear prompting you to register as a user.
3. Enter your phone number or email address to receive a registration code.
4. Fill in the registration code and follow the on-screen instructions.
5. Set a password to complete the registration process.
1. Open the "Bird Lover" app and click on "Add Device" in the upper
right corner.
2. Select the corresponding bird feeder (Smart Bird Feeder/BF 11) from the available options.
3. Follow the on-screen steps and click "Next."
1. Locate the reset button on the top of the camera.
2. Using a reset needle, hold down the reset button for five seconds at the reset position.
3. After hearing a ding sound, press "Next" on your phone.
4. The red light on the camera will start flashing quickly.
5. Connect your phone to the Wi-Fi network.
6. A barcode will appear on your phone's screen.
7. Align the barcode with the camera and let the camera scan it.
8. After hearing another ding sound, the pairing is successful.
9. Click "OK" on your phone to complete the pairing process.
